> Speaker SB ACOUSTICS 6.5" 4Ω MID-WOOFER - Round Frame
Speaker SB ACOUSTICS 6.5" 4Ω MID-WOOFER - Round Frame View larger
Previous Next

Speaker SB ACOUSTICS 6.5" 4Ω MID-WOOFER - Round Frame

SPK0553

New product

Speaker SB ACOUSTICS MID-WOOFER

6.5 Inch

4Ω

Need Help? Click Here

More details

Special Order : BACKORDER ETA 3-5 day delay to order in from suppliers warehouse.

Add to wishlist

More info

Vented cast aluminium chassis for optimum strength and low compression.

Soft low damping rubber surround for improved transient response.

Non-conducting fibre glass voice coil former for minimum damping.

Extended copper sleeve on pole piece for low inductance and low distortion.

CCAW voice coil for reduced moving mass.

Vented pole piece for reduced compression.

SPECIFICATION -
Le 0.13mH
Qts 0.28
Qes 0.3
Rms 0.45kg/s
Mag. 0.54kg
QTY 1
Sd 118cm²
Mms 12.3g
Diam. 152mmØ
Page 16
Width 171mmØ
Cms 2.29mm/N
Re 3.1Ω
Fs 30Hz
Coil 35.5mmØ
Impedance (Ohm) 4 ohm
Vas 45L
Zn 4Ω
Impedance 4Ω (Re 3.1Ω)
Qms 5.2
Power (RMS) 51-100 Watt
Inch 6.5
Size 6.5"
Prms 60W
Power 60Wrms
Depth 86mm
Sens. 90dB
Type Mid-Woofer
Series Poly Cones
Materials Polypropylene
Brand SB Acoustics
